🐘 PostgreSQL on Kubernetes with ArgoCD and Zalando Operator (and SSL & S3 Backups, of course)

I needed a PostgreSQL database for this website (yep, the one you're browsing), because I'm using Strapi as a headless CMS. I wanted something:

• Easy to deploy ✅
• Robust enough for production ✅
• Properly secured (SSL!) ✅
• With automatic daily backups to S3 ✅

As usual, “easy” is a relative term. So here’s exactly how I did it — with code snippets, kubectl tips, and a few caveats I ran into. You're welcome 😎

---

⚙️ Architecture overview

• Kubernetes cluster hosted on DigitalOcean (using their managed K8s service).
• ArgoCD for GitOps-based deployment.
• Zalando Postgres Operator for managing PostgreSQL clusters.
• Strapi as the consumer of the database.
• TLS encryption between app and DB, using a self-signed cert.
• Backups to DigitalOcean Spaces (S3-compatible).

---

📦 Deploy the Zalando PostgreSQL Operator

The operator lives in the main namespace. Here's the ArgoCD application definition:

Copy
1apiVersion: argoproj.io/v1alpha1
2kind: Application
3metadata:
4  name: postgres-operator
5  namespace: argocd
6  finalizers:
7    - resources-finalizer.argocd.argoproj.io
8spec:
9  project: default
10  source:
11    repoURL: 'git@github.com:bv86/k8s-infra.git'
12    targetRevision: HEAD
13    path: kustomize/postgres-operator/base
14  destination:
15    server: "https://kubernetes.default.svc"
16    namespace: main
17  syncPolicy:
18    automated:
19      prune: true
20      selfHeal: true
21    syncOptions:
22      - CreateNamespace=true

And here's the kustomization.yaml file from kustomize/postgres-operator/base to make sure everything runs in the correct namespace:

Copy
1apiVersion: kustomize.config.k8s.io/v1beta1
2kind: Kustomization
3
4resources:
5  - github.com/zalando/postgres-operator/manifests?ref=v1.14.0
6
7patches:
8  # by default, service account is created in the default namespace, so add another one in the proper namespace
9  - target:
10      version: v1
11      kind: ServiceAccount
12      name: postgres-operator
13    patch: |-
14      - op: replace
15        path: /metadata/namespace
16        value: main

---

🔒 Generate a self-signed SSL certificate

Node.js is very picky about SSL. Here's how I generated a certificate signed by my own CA:

1. Generate the CA key and certificate

Copy
1openssl req -x509 -newkey rsa:4096 -days 9000 \
2  -nodes -keyout ca-key.pem -out ca-cert.pem \
3  -subj "/CN=MyPGSQL_CA"

2. Generate a server key and certificate signing request

Copy
1openssl req -newkey rsa:4096 -nodes \
2  -keyout server-key.pem -out server-req.pem \
3  -subj "/CN=acid-strapi.main.svc.cluster.local"

☝️ Important: CN must match the internal service name exactly.

3. Sign the server certificate

Copy
1openssl x509 -req -in server-req.pem -CA ca-cert.pem \
2  -CAkey ca-key.pem -CAcreateserial -out server-cert.pem -days 3650

4. Store it in Kubernetes

Copy
1kubectl create secret generic pg-tls \
2  --from-file=tls.crt=server-cert.pem \
3  --from-file=tls.key=server-key.pem \
4  --from-file=ca.crt=ca-cert.pem \
5  -n main

---

🛠 Deploy the PostgreSQL cluster

🔐 Secret for Spaces credentials

First, let's create a secret containing the DigitalOcean access and secret key for my S3 compatible storage:

Copy
1kubectl create secret generic app-secrets \
2  --from-literal=DO_SPACE_ACCESS_KEY="your-access-key" \
3  --from-literal=DO_SPACE_SECRET_KEY="your-secret-key" \
4  -n main

The PostgreSQL instance

This is part of my my-strapi ArgoCD app. Here’s the CRD (postgresql.acid.zalan.do) definition:

Copy
1apiVersion: "acid.zalan.do/v1"
2kind: postgresql
3metadata:
4  name: acid-strapi
5  namespace: main
6spec:
7  teamId: "acid"
8  spiloFSGroup: 103
9  volume:
10    size: 1Gi
11  numberOfInstances: 2
12  tls:
13    secretName: "pg-tls"
14    caFile: "ca.crt"
15  users:
16    benoit:
17      - superuser
18      - createdb
19  preparedDatabases:
20    strapi:
21      defaultUsers: true
22  postgresql:
23    version: "17"
24  env:
25    - name: WAL_S3_BUCKET
26      value: strapi-bucket-ben
27    - name: AWS_ACCESS_KEY_ID
28      valueFrom:
29        secretKeyRef:
30          name: app-secrets
31          key: DO_SPACE_ACCESS_KEY
32    - name: AWS_SECRET_ACCESS_KEY
33      valueFrom:
34        secretKeyRef:
35          name: app-secrets
36          key: DO_SPACE_SECRET_KEY
37    - name: AWS_ENDPOINT
38      value: "https://lon1.digitaloceanspaces.com"
39    - name: BACKUP_SCHEDULE
40      value: "0 1 * * *"  # Daily at 1AM

---

📦 Strapi Configuration

Strapi connects to the DB with SSL enabled and custom certificates. Here's what I set up:

Environment config

I use a ConfigMap to store non sensitive DB information.

Copy
1apiVersion: v1
2kind: ConfigMap
3metadata:
4  name: strapi-database-conf
5data:
6  DATABASE_HOST: acid-strapi.main.svc.cluster.local
7  DATABASE_PORT: "5432"
8  DATABASE_NAME: strapi
9  DATABASE_USERNAME: strapi_owner_user
10  DATABASE_SSL: "true"
11  DATABASE_CLIENT: postgres

My strapi Deployment definition

Copy
1apiVersion: apps/v1
2kind: Deployment
3metadata:
4  name: strapi-app
5spec:
6  replicas: 1
7  selector:
8    matchLabels:
9      app: strapi-app
10  template:
11    metadata:
12      labels:
13        app: strapi-app
14    spec:
15      imagePullSecrets:
16        - name: ghcr-credentials
17      volumes:
18        - name: certs
19          secret:
20            secretName: pg-tls
21      containers:
22        - name: strapi
23          image: ghcr.io/bv86/my-strapi:main
24          ports:
25            - containerPort: 1337
26              name: http
27          envFrom:
28            - configMapRef:
29                name: strapi-app-conf # the name of our ConfigMap for our app.
30            - configMapRef:
31                name: strapi-database-conf # the name of our ConfigMap for our app.
32            - configMapRef:
33                name: strapi-s3-conf # the name of our ConfigMap for our app.
34            - secretRef:
35                name: app-secrets # the name of our Secret for our app.
36          env:
37            - name: DATABASE_PASSWORD
38              valueFrom:
39                secretKeyRef:
40                  name: strapi-owner-user.acid-strapi.credentials.postgresql.acid.zalan.do
41                  key: password
42            - name: NODE_EXTRA_CA_CERTS
43              value: /etc/certs/ca.crt
44          volumeMounts:
45            - name: certs
46              mountPath: /etc/certs
47              readOnly: true

As you can see, I load the values from my ConfigMap as environment variables.

The strapi-owner-user.acid-strapi.credentials.postgresql.acid.zalan.do secret is managed by the PostgreSQL operator and contains the user's password.

Another important part is the mounting of ca.cert from pg-tls as a file in /etc/certs, this is so that Node.js can be told to trust that certificate.

At last, in strapi, the database configuration looks like this:

Copy
1postgres: {
2      connection: {
3        connectionString: env('DATABASE_URL'),
4        host: env('DATABASE_HOST', 'localhost'),
5        port: env.int('DATABASE_PORT', 5432),
6        database: env('DATABASE_NAME', 'strapi'),
7        user: env('DATABASE_USERNAME', 'strapi'),
8        password: env('DATABASE_PASSWORD', 'strapi'),
9        ssl: env.bool('DATABASE_SSL', false) && {
10          key: env('DATABASE_SSL_KEY', undefined),
11          cert: env('DATABASE_SSL_CERT', undefined),
12          ca: env('DATABASE_SSL_CA', undefined),
13          capath: env('DATABASE_SSL_CAPATH', undefined),
14          cipher: env('DATABASE_SSL_CIPHER', undefined),
15          rejectUnauthorized: env.bool(
16            'DATABASE_SSL_REJECT_UNAUTHORIZED',
17            true
18          ),
19        },
20        schema: env('DATABASE_SCHEMA', 'public'),
21      },
22      pool: {
23        min: env.int('DATABASE_POOL_MIN', 2),
24        max: env.int('DATABASE_POOL_MAX', 10),
25      },
26    }

---

🧪 Debugging tips

• Use psql from another pod to test SSL:

Copy
1psql "sslmode=verify-full host=acid-strapi.main.svc.cluster.local dbname=strapi user=strapi_owner_user sslrootcert=/etc/certs/ca.crt"

• Check logs of the Zalando operator:

Copy
1kubectl logs -l name=postgres-operator -n main

---

✅ Conclusion

With this setup, I now have:

• A production-ready PostgreSQL setup
• SSL/TLS encryption between my app and the DB
• Automated daily backups
• GitOps magic with ArgoCD ✨

Next steps? Probably automate cert creation with let's encrypt.
